NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial

1000pcs
MOQ
$ 0.8-10 pcs
Price
NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Brass Hpb57-3
Tube: Glass Tube
Thread: BSP,NPT,Metric Thread
Basic Infomation
Place of Origin: China
Brand Name: grandmfg
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 100000/month
Product Description

Housing: Brass Tube .

Tube: Real glass tube.

O-Ring and flat gaskets: NBR Rubber.

Thread szie: M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”

Temperature resistant: -20’C to 120 ‘C. / 0’F to 260 ‘F

Distance of two bolts: 80mm to 600mm

Usage: Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 0

item brass sight gauges
Housing brass tube
tube quartz glass tube
O-Ring and flat gaskets NBR Rubber
Thread szie M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”,
G1/2”, NPT1/4, NPT3/8, NPT1/2”
Temperature resistant : -20’C to 120 ‘C. / 0’F to 260 ‘F
Distance of two bolts 80mm to 600mm

NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 1NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 2NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 3NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 4NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 5

NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 6

NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 7NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 7NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 9

NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 10NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 11

NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 12

item Hydraulic oil level indicator
Housing Aluminum alloy housing and inside thermoplastic (PC)
O-Ring and flat gaskets NBR Rubber
Reflector aluminum with printed white
Bolt M10 Hexagon nut and washer in galvanized steel
Temperature resistant : -20’C to 100 ‘C. / 0’F to 220 ‘F
Distance of two bolts 50mm to 500mm
Usage Thin-wall container, Radiator, Hydraulic reservoir and receivers.



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 13NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 14NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 15



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 16NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 17NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 18

item brass sight glasses
material brass
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 19NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 20



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 21

item brass breather vent plugs
material brass or aluminum
Thread Type BSP,Metric,NPT
finish Natural and Nickel Plated
size Any Size OEM are welcome.
Work Pressure 0.005 MPa to M 0.03 Mpa
Tempture Range : -30 Cent degree to 130 Cent degree.
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers,
Gearboxes, Speed Reducer, Compressor and Power Transmission.



NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 22NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 23NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 24NPT pipe thread 1/2",3/4",1",1-1/4",1-1/2" observation oil level gauges for industrial 25



Please contact us for checking our stocks and confirming the specifications.
