Name: NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge
Brand: grand-mfg
SKU: 1/2",3/4",1",11/2",11/4",13/4",2"
Price: 0.8 USD
Availability: InStock
Rating: 4.9 (143 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Material: Brass Hpb57-3

Thread: BSP,NPT,Metric Thread

Finish: No Finishing

Window: Natural Glass

Glass Thickness: 2mm-5mm

Basic Infomation

Place of Origin: China

Brand Name: grand-mfg

Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"

Payment & Shipping Terms

Packaging Details: exporting packaging

Delivery Time: 45 work days

Payment Terms: T/T

Supply Ability: 50000/month

Gallery

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge

Product Description

Housing: Brass Tube .

Tube: Real glass tube.

O-Ring and flat gaskets: NBR Rubber.

Thread szie: M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”

Temperature resistant: -20’C to 120 ‘C. / 0’F to 260 ‘F

Distance of two bolts: 80mm to 600mm

Usage: Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes,

Speed Reducer, Compressor and Power Transmission.

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge 0

item	brass sight gauges
Housing	brass tube
tube	quartz glass tube
O-Ring and flat gaskets	NBR Rubber
Thread szie	M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”
Temperature resistant	: -20’C to 120 ‘C. / 0’F to 260 ‘F
Distance of two bolts	80mm to 600mm

item	Hydraulic oil level indicator
Housing	Aluminum alloy housing and inside thermoplastic (PC)
O-Ring and flat gaskets	NBR Rubber
Reflector	aluminum with printed white
Bolt	M10 Hexagon nut and washer in galvanized steel
Temperature resistant	: -20’C to 100 ‘C. / 0’F to 220 ‘F
Distance of two bolts	50mm to 500mm
Usage	Thin-wall container, Radiator, Hydraulic reservoir and receivers.

item	plastic sight glasses
material	plastic
seal	NBR
Reflectors	Plastic PMMA
Resist Tempreature Range	: -30'C to 70'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	Metric and BSP(G thread)

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge 1

Item	Flat flange sight glass
Material	steel nickel plated
Window	Natural Glass
Glass Thickness	2mm to 5 mm
Working Tempreature	: －40℃～200℃
Temperature Assaults Date	: －40℃～180℃
Working Pressure	2.5, 4.0Mpa
Our products are provided with simple structure, novel appearance, high airproof, well poressure, good anti-cold concussion, marked clearly in the indication of liquid location etc characters, and favor of the spacious domestic and overseas air compressor producer deeply.


Item	Fused sight glass
Material	steel nickel plated
Window	Natural Glass
Glass Thickness	2mm to 5 mm
Working Tempreature	: －40℃～200℃
Temperature Assaults Date	: －40℃～180℃
Working Pressure	2.5, 4.0Mpa
Our products are provided with simple structure, novel appearance, high airproof, well poressure, good anti-cold concussion, marked clearly in the indication of liquid location etc characters, and favor of the spacious domestic and overseas air compressor producer deeply.

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge 3

item	brass breather vent plugs
material	brass or aluminum
Thread Type	BSP,Metric,NPT
finish	Natural and Nickel Plated
size	Any Size OEM are welcome.
Work Pressure	0.005 MPa to M 0.03 Mpa
Tempture Range	: -30 Cent degree to 130 Cent degree.
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.

item	Magnetic oil drain plugs
material	Steel and Aluminum
Magnet Material	NdFeb magnets and Ferrite magnets
Thread Type	BSP,Metric
finish	Steel Zinc plated, Aluminum Natural and Aluminum Oxidized Color.
size	Metric thread,NPT Thread and BSP thread. OEM is welcome.
Usage	Auto engineer,gearbox,pump,oil tank and speed reducer.

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge 4

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 11/4",11/2",2" Fuel Tank Gauges Hydraulic Oil Level Gauge for Industrial Brass Tube Oil Level Gauge 5
