Name: Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge
Brand: Grand Hardware Manufacturing Co.,Ltd
SKU: 1/2",3/4",1",11/2",11/4",13/4",2"
Price: 4.80 USD
Availability: InStock

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge

1000pcs

MOQ

$ 0.8-10 pcs

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Material: Brass Hpb57-3

Tube: Glass Tube

Thread: BSP,NPT,Metric Thread

Basic Infomation

Place of Origin: China

Brand Name: grand-mfg

Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"

Payment & Shipping Terms

Packaging Details: exporting packaging

Delivery Time: 45 work days

Payment Terms: T/T

Supply Ability: 100000/month

Gallery

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge

Product Description

Housing: Brass Tube .

Tube: Real glass tube.

O-Ring and flat gaskets: NBR Rubber.

Thread szie: M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”

Temperature resistant: -20’C to 120 ‘C. / 0’F to 260 ‘F

Distance of two bolts: 80mm to 600mm

Usage: Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes,

Speed Reducer, Compressor and Power Transmission.

item	brass sight gauges
Housing	brass tube
tube	quartz glass tube
O-Ring and flat gaskets	NBR Rubber
Thread szie	M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”
Temperature resistant	: -20’C to 120 ‘C. / 0’F to 260 ‘F
Distance of two bolts	80mm to 600mm

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge 0

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge 1

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge 3

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge 4

item	Hydraulic oil level indicator
Housing	Aluminum alloy housing and inside thermoplastic (PC)
O-Ring and flat gaskets	NBR Rubber
Reflector	aluminum with printed white
Bolt	M10 Hexagon nut and washer in galvanized steel
Temperature resistant	: -20’C to 100 ‘C. / 0’F to 220 ‘F
Distance of two bolts	50mm to 500mm
Usage	Thin-wall container, Radiator, Hydraulic reservoir and receivers.

Metric thread M10 M12 M16 M18 Observation Oil Level Sight Gauges For Industrial Hydraulic Oil Level Gauge 5

Please contact us for checking our stocks and confirming the specifications.
