Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China

500pcs
MOQ
$ 0.8-10 pcs
Price
Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Brass,Stainless Steel 304 316
Finishing: No Finishing
Pressure: Normal Pressure / High Pressure
Designs: Designed As Your Requirements
Basic Infomation
Place of Origin: China
Brand Name: grand-mfg
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging or as required.
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 50000/month
Product Description
  • Material Body: Brass



  • O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal



  • Glass Thickness: 2mm to 5 mm



  • Reflectors: Stainless Steel 304 Reflector

         (Any type you can chose with reflector or without Reflector, You also can add float ball.)


  • Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass
  • Resist Tempreature Range:-30'C to 120'C
  • Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).



  • Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)



  • Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.
  • Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.

Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 0Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 1Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 2Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 3

item brass sight glasses
material brass
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 4

Item Fused sight glass
Material steel nickel plated
Window Natural Glass
Glass Thickness 2mm to 5 mm
Working Tempreature : －40℃～200℃
Temperature Assaults Date : －40℃～180℃
Working Pressure 2.5, 4.0Mpa
Our products are provided with simple structure, novel appearance, high airproof,
well poressure, good anti-cold concussion, marked clearly in the indication of
liquid location etc characters, and favor of the spacious domestic and overseas
air compressor producer deeply.

Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 5

item SS sight glasses
material Stainless steel 304,Stainless steel 304L,Stainless Steel 316,
Stainless steel 316L
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)



Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 6Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 7

Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 8

item aluminum sight glasses
material body Aluminum 6061 T6/Aluminum 6063
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector
(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type UNC,UNF,Metric and BSP(G thread)
size Below you will get the size you wanted.Another size is okay.
OEM are welcome.
Usage Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.



Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 9Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 10Dome brass oil glass sights NPT 1/2" 3/4" custom available professional manufacturer in China 11



FAQ
1.What is your MOQ, Delivery time? Ship from which port?
Our MOQ from 20-1000 Pcs different according items.The retail orders from ultimate customers are available if the item in stock. We usually ship bulk goods within 45 days from Ningbo port.
2.Can I get sample for quality checking before order?
Yes. Although we have a complete product quality inspection systerm, we also hope to confirm the new project before order.We could offer sample for free but do not pay the express charge.
3.Can you customize products for your customers?
Yes. Customized service is a part of our business. Any special requirements,just please contact us.
4.Do you have products in stock?
Yes. Many common sizes of products in stock. We hope that it is helpful for our customers' urgent small order.
5.If we get quality problem or wrong sizes, how to solve?
Please check the goods once you get.
If we ship wrong products (for example :wrong sizes) or you get quality problem, don't worry, just please contact us immediately, we will take our responsibility. About some items, we sure that our products' sevice life as same as your equipments' service life. You will get what you pay for.
6.How to contact Yuhuan Yize Machinery Factory ( Grand Hardware Manufacturing Co.,Ltd.)?
Please visit our website: www.grandmfgcn.com .
　 　 　
Q1.What is your MOQ, Delivery time? Ship from which port?
A: Our MOQ from 20-1000 Pcs different according items.The retail orders from ultimate customers are available if the item in stock. We usually ship bulk goods within 45 days from Ningbo port.

Q2. Can I get sample for quality checking before order?
A: Yes. Although we have a complete product quality inspection system, we also hope to confirm the new project before order.We could offer sample for free but do not pay the express charge.

Q3. Can you customize products for your customers?
A: Yes. Customized service is a part of our business. Any special requirements,just please contact us.

Q4. Do you have products in stock?
A: Yes. Many common sizes of products in stock. We hope that it is helpful for our customers' urgent small order.


Q5. If we get quality problem or wrong sizes, how to solve?
A: Please check the goods once you get. If we ship wrong products (for example :wrong sizes) or you get quality problem, don't worry, just please contact us immediately, we will take our responsibility. About some items, we sure that our products' service life as same as your equipments' service life. You will get what you pay for.

Q6. How to contact Yuhuan Yize Machinery Factory ( Grand Hardware Manufacturing Co.,Ltd.)?
A: Please visit our website: www.grandmfgcn.com .

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them.
