Home /Products/Brass Oil Sight Glass/NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34

NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34

1000pcs
MOQ
$ 0.8-10 pcs
Price
NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Brass Hpb57-3
Window: Natural Glass
Glass Thickness: 2mm-8mm
Thread: BSP,NPT,Metric Thread
Service: OEM And ODM Business
Basic Infomation
Place of Origin: China
Brand Name: grand-mfg
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 50000/month
Product Description



Material Body: Brass

O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal

Glass Thickness: 2mm to 5 mm

Reflectors: Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)

Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass

Resist Tempreature Range:-30'C to 120'C

Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).

Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.

Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.





item brass sight glasses
material brass
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)





NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34 0NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34 1









item brass sight glasses
material brass
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)







----------------------------SHIPPING-------------------------------------







NPT male thread 1/2 3/4 1-1/4 1-1/2 2 inch bulls eye oil sight glass supplier viewport liquid level gauge GM-BN34 2



www.grand-mfg.com
