Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass

1000pcs
MOQ
$ 0.8-10 pcs
Price
Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Brass Hpb57-3
Connection: Thread
Finish: Natural
Window: Natural Glass
Glass: Flat Glass
Basic Infomation
Place of Origin: China
Brand Name: grandmfg
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging or as required.
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 100000/month
Product Description

Material Body: Brass

O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal

Glass Thickness: 2mm to 5 mm

Reflectors: Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)

Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass

Resist Tempreature Range:-30'C to 120'C

Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).

Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.

Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.





item brass sight glasses
material brass
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)



Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 0Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 1Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 2Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 3Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 4Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 5Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 6Npt 1/2 inch thread safety sight glass assembly for trucks with flat glass 7



Confirming the specifications and chekcing our stocks just please contact us by email ( grandmfg@vip.126.com)

Grace

sales department
