Name: BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier
Brand: grand-mfg
SKU: 1/2",3/4",1",11/2",11/4",13/4",2"
Price: 0.8 USD
Availability: InStock
Rating: 4.9 (153 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Material: Carbon Steel ( Al 6061 )

Thread: BSP,NPT,Metric

Glass Type: Natural Glass,tempered Glass,borosilicate Glass

Surface Treatment: Nickel Plated

Basic Infomation

Place of Origin: China

Brand Name: grand-mfg

Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"

Payment & Shipping Terms

Packaging Details: exporting packaging

Delivery Time: 45 work days

Payment Terms: T/T, Western Union

Supply Ability: 100000/month

Gallery

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier

Product Description

Material Body: Stainless steel 304,Stainless steel 304L,Stainless Steel 316,Stainless steel 316L

O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal

Glass Thickness: 2mm to 5 mm

Reflectors: Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)

Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass

Resist Tempreature Range:-30'C to 120'C

Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).

Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.

Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.

item	steel sight glasses
material	steel
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier 0

item	magnetic oil drain plugs
material	steel
finish	FinishSteel Zinc plated,Aluminum Natural and Aluminum Oxidized Color.
size	12x1.25 MM12x 1.5and M14 x 1.5.
usage	auto engineer

item	Magnetic oil drain plugs
material	Steel and Aluminum
Magnet Material	NdFeb magnets and Ferrite magnets
Thread Type	BSP,Metric
finish	Steel Zinc plated, Aluminum Natural and Aluminum Oxidized Color.
size	Metric thread,NPT Thread and BSP thread. OEM is welcome.
Usage	Auto engineer,gearbox,pump,oil tank and speed reducer.

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier 1

item	brass breather vent plugs
material	brass or aluminum
Thread Type	BSP,Metric,NPT
finish	Natural and Nickel Plated
size	Any Size OEM are welcome.
Work Pressure	0.005 MPa to M 0.03 Mpa
Tempture Range	: -30 Cent degree to 130 Cent degree.
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier 3

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier 5

item	brass sight glasses
material	brass
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

BSP thread sight glass 1/2",3/8"1/4,1" NPT steel oil sight indicators gearbox oil level sight glass supplier 6

item	sight glasses,oil gauges
	oil drain plugs,steel plugs
	breather vent plugs
	auto radiator parts
	magnetic drain plugs
	precision machined parts(brass,steel,stainless steel,aluminum) hydraulic steel fittings OEM and ODM business welcome.
website	www.grand-mfg.com
sales department	Grace
Email	grandmfg@vip.126.com

Tag:

Tel :	86-139-6762 1509
Fax :	86-576-88327473
