Home /Products/Flange Sight Glass Window/Compressor Flange Sight windows Nickel Plated,easy to mount on equipment

Compressor Flange Sight windows Nickel Plated,easy to mount on equipment

100pcs
MOQ
$ 0.8-10 pcs
Price
Compressor Flange Sight windows Nickel Plated,easy to mount on equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Steel
Finish: Nickel Plated
Assemble: Easy To Mount On Equipment
Basic Infomation
Place of Origin: China
Brand Name: Grand
Certification: ISO9001
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging or as required.
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 20000/month
Product Description

Steel Flange fused sight glass, Steel Flange fused sight glass, Steel flange fused glass window, Steel flange window sight

Flange sight glasses are used widely to observe the liquid medium inside of refrigeration machine, compressor and various machines.



Flange sight glass Main technical parameter:

Working pressure: 2.5, 4.0Mpa

Working temperature: -40 degree to 200 degree

Temp difference impact data: -40 degree to 180 degree



Our products are provided with simple structure, novel appearance, high airproof, and well pressure, good anti-cold concussion, marked clearly in the indication of liquid location etc characters, and favor of the spacious domestic and overseas air compressor producer deeply.

Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 0

Item Flat flange sight glass
Material steel nickel plated
Window Natural Glass
Glass Thickness 2mm to 5 mm
Working Tempreature : －40℃～200℃
Temperature Assaults Date : －40℃～180℃
Working Pressure 2.5, 4.0Mpa
Our products are provided with simple structure, novel appearance, high airproof,
well poressure, good anti-cold concussion, marked clearly in the indication of
liquid location etc characters, and favor of the spacious domestic and overseas
air compressor producer deeply.



Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 1Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 2Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 3Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 4Compressor Flange Sight windows Nickel Plated,easy to mount on equipment 5

Tag:

liquid sight glass

fused glass liquid sight glass

flange fused sight glass
