Name: Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C
Brand: grand-mfg
SKU: grand-mfg
Rating: 4.8 (127 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Material: Aluminium,brass,ss304

Thread: BSP,METRIC THREAD,NPT,UNF

Size: 1/8,1/4,1/2,3/4,1",11/4",11/2"

Highlight:

oil level indicator

sight glass

sight gauge

Basic Infomation

Place of Origin: CHINA

Brand Name: grand-mfg

Payment & Shipping Terms

Packaging Details: CARTONS

Delivery Time: 15 work days

Payment Terms: T/T

Supply Ability: 10000

Gallery

Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C

Product Description

Aluminum Body Sight Glass or Oil Level Indicator.Project Equipment offers valves,

pipes, tubes, pipe fittings, etc.The Aluminium Body Sight Glass or Oil level Indicator

is provided with heat and oil resistance Viton rubberIt is capable of withstanding

temperature of up to 120 degree C.This Oil Level Indicator is used in all kinds of

gear box, pumps, compressors, gear motor, hoists, hydraulic and pneumatic systems.

This Aluminium Body Sight Glass or Oil level Indicator is available in 1/4, 3/8, 3/4, 1 1/4,

1/2, 1 and 1 1/2 inches BSP,M10 to M48, Npt thread is okay too.

item	aluminum sight glasses
material body	Aluminum 6061 T6/Aluminum 6063
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	UNC,UNF,Metric and BSP(G thread)
size	Below you will get the size you wanted.Another size is okay. OEM are welcome.
Usage	Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.

Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C 0

item	SS sight glasses
material	Stainless steel 304,Stainless steel 304L,Stainless Steel 316, Stainless steel 316L
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C 1

item	brass sight glasses
material	brass
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C 2

item	brass breather vent plugs
material	brass or aluminum
Thread Type	BSP,Metric,NPT
finish	Natural and Nickel Plated
size	Any Size OEM are welcome.
Work Pressure	0.005 MPa to M 0.03 Mpa
Tempture Range	: -30 Cent degree to 130 Cent degree.
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.

Aluminum Oil Level Sight Glass for Hydraulic and Pneumatic Systems Aluminum Oil Sight Gauge for High-Temperature Applications up to 120°C 3
