Home /Products/Stainless Steel liquid Sight Glass/NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass

1000pcs
MOQ
$ 0.8-10 pcs
Price
NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Ss304, Ss316
Thread: BSP,NPT,Metric Thread
Finish: No Finishing
Window: Natural Glass
Glass Thickness: 2mm-5mm
Basic Infomation
Place of Origin: China
Brand Name: grand-mfg
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 50000/month
Product Description

Material Body: Stainless steel 304,Stainless steel 304L,Stainless Steel 316,Stainless steel 316L

O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal

Glass Thickness: 2mm to 5 mm

Reflectors: Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)

Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass

Resist Tempreature Range:-30'C to 120'C

Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).

Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.

Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.

item SS sight glasses
material Stainless steel 304,Stainless steel 304L,Stainless Steel 316,
Stainless steel 316L
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass 0

item aluminum sight glasses
material body Aluminum 6061 T6/Aluminum 6063
O-Ring Viton,FKM,NBR, Aramid gasket and Copper seal
window Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness 2mm to 5 mm
Reflectors Stainless Steel 304 Reflector
(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range .-30'C TO 120'C
Pressure Range 5-10 Bar(0.5MPa to 1 MPa).
Thread type UNC,UNF,Metric and BSP(G thread)
size Below you will get the size you wanted.Another size is okay.
OEM are welcome.
Usage Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.



NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass 1

NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass 2NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass 3NPT,BSP,G thread,Metric thread1/2",3/4", 1", 2"Stainless Steel 304 Oil level indicator sight glasses Stainless Steel liquid Sight Glass with Borosilicate Glass 4





Please contact us for checking our stocks and confirming specifications.
