Home /Products/Fused Sight Glass window/male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights

male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights

1000pcs
MOQ
$ 0.8-10 pcs
Price
male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Steel
Surface Treatment: Nickel Plated
Size: 1/2",3/8"1/4,1",11/4",11/2",13/4",2"
Window: Glass
Basic Infomation
Place of Origin: China
Brand Name: grandmfg
Certification: ISO9001
Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"
Payment & Shipping Terms
Packaging Details: exporting packaging
Delivery Time: 45 work days
Payment Terms: T/T
Supply Ability: 100000/month
Product Description

Threaded Fused Window Sights,Fused Sight Glass,Fused level sight gauge,Fused Sight windows,Metal Sight Glass


Specifications:


Service: Compatible gases and liquids.


Window: nature glass (3mm to 6mm)


Body: Nickel Plated steet,stainless steel 304 and S.S 316


Reflector: S.S 304 Customers can chosed Plastic float Ball for oil or other liquid.


Temperature: -30'C to 260 'C (500 ‘F).

Max Pressure: 12 MPa(1740Psi)


Connections: NPT,NPTF,UNC,UNF,Metric and BSP (G thread)

Size: 1/4" to 2"

Usage: refrigeration machine, compressor,Hydraulic reservoir,Power Transimission and various machine.





Item Fused sight glass
Material steel nickel plated
Window Natural Glass
Glass Thickness 2mm to 5 mm
Working Tempreature : －40℃～200℃
Temperature Assaults Date : －40℃～180℃
Working Pressure 2.5, 4.0Mpa
Our products are provided with simple structure, novel appearance, high airproof,
well poressure, good anti-cold concussion, marked clearly in the indication of
liquid location etc characters, and favor of the spacious domestic and overseas
air compressor producer deeply.



male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 0male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 1male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 2male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 3male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 4male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 5male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 6male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 7male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 8male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 9male NPT,BSP thread 1 inch,Metric thread M33 nickel plated steel fused oil level sights 10



Retail is available for some items in stock. Any more details please contact us.
