Home /Products/Stainless Steel liquid Sight Glass/Stainless steel 316 oil sight glass

Stainless steel 316 oil sight glass

500
MOQ
Stainless steel 316 oil sight glass
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Brand Name: Grand
Payment & Shipping Terms
Product Description

Stainless steel Oil level Sight glass, oil sight gauge, oil sight gage, oil level indicator, liquid sight glass, sight window, view ports, male thread sight glasses, domed sight glass plug
Material
Body: SS304, SS304L, SS316, SUS316L SUS304, SUS304L, SUS316, SUS316L
O-Ring: Viton and NBR
Glass: Natural Glass
Glass Thickness: 2mm to 5 mm
Glass Type: General Glass, Tempered Glass and Borosilicate Glass
Resist Temperature Range: -30 Centigrade to 120 Centigrade.

Pressure Range: 5-10 Bar or 0.5MPa to 1 MPa.

Connections: NPTF, NPT, UNC, UNF, Metric and BSP (G thread)

Size:M10X1, M16X1.5,M20X1.5, ,M27X1.5,M33X1.5,
G 3/8,G 1/2,G 3/4,G 1 NPT 3/8, NPT 1/2,NPT 3/4,NPT 1

MOQ: 2000 Pcs each size

Delivery time: 20 days.

Usage: Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.
