Name: BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier
Brand: Grand Hardware Manufacturing Co.,Ltd
SKU: 1/2",3/4",1",11/2",11/4",13/4",2"
Price: Negotiable USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Material: Aluminium

Finish: Natural

Service: OEM And ODM Business

Basic Infomation

Place of Origin: China

Brand Name: grand-mfg

Model Number: 1/2",3/4",1",11/2",11/4",13/4",2"

Payment & Shipping Terms

Packaging Details: cartons and pallets

Gallery

BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier

Product Description

Web: www grandmfgcn com
Aluminum Oil Sight Glass, Oil Level Indicator. Aluminum oil level gauge
Project Equipment offers valves, pipes, tubes, pipe fittings, etc.
The Aluminum Body Sight Glass or Oil level Indicator is provided with heat and oil resistance Viton rubber
It is capable of withstanding temperature of up to 120 degree C.
This Oil Level Indicator is used in all kinds of gear box, pumps, compressors, gear motor, hoists,
hydraulic and pneumatic systems.
This Aluminum Body Sight Glass or Oil level Indicator is available in 1/4, 3/8, 3/4, 1 1/4, 1/2, 1
and 1 1/2 inches BSP,M10 to M48, Npt thread is available.

item	aluminum sight glasses
material body	Aluminum 6061 T6/Aluminum 6063
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	UNC,UNF,Metric and BSP(G thread)
size	Below you will get the size you wanted.Another size is okay. OEM are welcome.
Usage	Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.

BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier 0

item	SS sight glasses
material	Stainless steel 304,Stainless steel 304L,Stainless Steel 316, Stainless steel 316L
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier 1

item	brass sight glasses
material	brass
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier 2

item	brass sight gauges
Housing	brass tube
tube	quartz glass tube
O-Ring and flat gaskets	NBR Rubber
Thread szie	M10x1, M12x1.5, M14x1.5, M16x1.5, G1/4”, G3/8”, G1/2”, NPT1/4, NPT3/8, NPT1/2”
Temperature resistant	: -20’C to 120 ‘C. / 0’F to 260 ‘F
Distance of two bolts	80mm to 600mm

BSP G thread 1 inch Hexagon aluminum oil level sight glass with reflector for compressor,male thread oil sight plug supplier 3

item	brass breather vent plugs
material	brass or aluminum
Thread Type	BSP,Metric,NPT
finish	Natural and Nickel Plated
size	Any Size OEM are welcome.
Work Pressure	0.005 MPa to M 0.03 Mpa
Tempture Range	: -30 Cent degree to 130 Cent degree.
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	Pump, Thin-wall container, Radiator, Hydraulic reservoir, receivers, Gearboxes, Speed Reducer, Compressor and Power Transmission.
